Network standard

Wireless standard: IEEE 802. 11n、IEEE 802. 11g. IEEE 802. 11b

Wired standard: IEEE 802.3、IEEE 802. 3u

Wireless transmission rate

11n:Up to 150Mbps

11g:Up to 54Mbps

11b:Up to 11Mbps

Number of channels

1-14

Frequency Range

2. 4-2. 4835G

Transmit power

12-15DBM

interface

2 Ethernet ports/1 serial port/1 power interface

antenna

Antenna type

External antenna

Function parameter

WIFI working mode

STA/AP/STA+AP

WDS function

Support WDS wireless bridging

Wireless security

64/128/152 bit WEP encryption

WPA- PSK/WPA2- PSK, WPA/WPA2 security mechanism

Network management

Remote web management

Configuration file import and export

WEB software upgrade

Other parameters

Status Indicator

Status indication

Environmental standards

Operating temperature: -20-70C

Working humidity: 10% 90%RH (Non-condensing)

storage temperature: -40- 40C

Storage humidity: 5%-90%RH (Non-condensing)

Other properties

Band bandwidth is optional: 20MHz/40MHz, automatic
